1. 32 bit CPU(ROR 10u Sec )
2. 2-axis Synchronous Motion, 20 KHz PWM
3. Individual Communicate Circuit, Enhance Process Effect
4. Able To Edit The Parameter Among The Controller Operate
5. More Than Ten Units AUTO-PID Synchronous Function
6. Multi-Lingual Display Menu
7. Enhance Password & Safety Function
8. Display Customize Message Among The Controller Operate
9. Built-in Standard High Frequency Counter
10.Built-in Standard Real Time Clock (RTC)
11.PC Program Can Use For All Ladder Series Controller
12.Synchronous Process Mulit-Controllers’ Communication
13.LDATP Text Panel Can Plug & Play Directly
14.Built-in Standard RS-485 Port, Connect Remote IO Module
15.Memory Card Which Has Copy & Password Protection
16.Connect Encoder & Multi-Sensors Directly
17.Program Auto Back-Up
18.Built-in Standard MODBUS RTU/ASCII Protocol
19.RTC Adjusts Immediately. Battery For More Than 2 Years
20.Built-in RS-232 & RS-485*2 Port (Support Master & Slave)
21.Easy To DIN-Rail & Wall Mounting Installation
22.Smart PC Software, Needn’t Memorize Commands
23.Built-in Display Monitor
24.AML Memory Can Upload & Download Program Apace
25.Enhance Operate Effective Via Edit Menu (Display)
26.Error Code Quickly Display To Facilitate Repair
27.Cam Control Command, Speed Control Disc Command,Rapid Application
29.Input Filtering, Adjustable Bandwidth |
