WIFI Remote Modules

see more

WIFI Analog I/O Remote Module

A-12x Series

※ Analog Input 16-bit Resolution ,Burn-out Detection
※ Analog Output 12-bit Resolution
※ Support Analog Input/Output 0/4 ~20mA or 0~10V
※ Support PT-100 or PT-1000 (2/3/4-wired)
※ Support J,K,T,E,R,S,B Thermocouple
※ Support 10K/6.8K/4.7K/3.3K/3K/2.7K/2.252K/2.1K/2K/1.5K/1K Thermistor
※ WIFI Interface + RS-485 Interface + USB Interface
※ Hi-Speed RS-485 Interface (Max 921600bps)
※ Standard 2.4GHz IEEE 802.11 b/g (Wi-Fi)
※ Built-in Step Motor Driver, Connect Directly
※ Output Over Current Protection (OCP)
※ Output Over Thermal Protection (OTP)
※ Output Under Voltage Lockout (UVLO)
※ Support MODBUS TCP/IP, UDP/IP ,RTU ,ASCII
※ Able To Connect Wi-Fi AP,Internet Of Things (IOT),Industry 4.0
※ A-3290 Can Be Directly Connected To The Control Output,Without Any Controller
※ Free monitor PC software "YottaUtility"

A-12x Series Remote Module

WIFI Analog I/O Remote Modules, link text

A-12x Series Remote Module

WIFI Analog I/O Remote Modules, link text

A-12x Series Remote Module

WIFI Analog I/O Remote Modules, link text

Collect from Yottacontrol

Products

see more

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation): 2
Outputs: 2*(Souce Transistor)
Continuous Current: 10-35VDC(1A)
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Input/Output Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 4 (16-bit)
Analog input Type:2* 0/4~20mA + 2* PT-100/1000
Analog Outputs: 2 (12-bit)
Analog Outputs Type: 0/4 ~20mA
Input Impedance:Current: 100 Ω / RTD : 10 MΩ
Input Accuracy: ±0.1%
Interface: WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C
Temperature Ranges: (PT-100:-200~+600°C) (PT-1000:-200~+600°C)

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation): 4
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Input Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 8 (16-bit)
Analog input Type:0/4~20mA,J,K,T,E,R,S,BThermocouple,Thermistor
Input Impedance:Current: 100 Ω / Voltage : 10 MΩ
Input Accuracy: ±0.1%
Interface: WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C
Temperature Ranges:(J:-210~760°C) (K:-270~1,370°C) (T:-270~400°C) (E:-270~1,000°C) (R:0~1,750°C) (S:0~1,750°C) (B:0~1,800°C)
(Thermistor-10K-T2:0~100°C) (Thermistor-10K-T3:0~100°C) (Thermistor-6.8K:-10~100°C) (Thermistor-4.7K:-10~100°C) (Thermistor-3.3K:-20~100°C)
(Thermistor-3K:-20~100°C) (Thermistor-2.7K:-20~100°C) (Thermistor-2.252K:-20~100°C) (Thermistor-2.1K:-30~100°C) (Thermistor-2K:-30~100°C)
(Thermistor-1.5K:-40~100°C) (Thermistor-1K:-40~100°C)

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation): 16
Communication Baud Rate: 1200~115200bps
Isolation: YES(5000VDC)
Input Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Interface:WIFI + RS-485 + USB
Channel Independent Configuration: YES

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation):8
Outputs: 4*(Motor Driver)
Continuous Current: 8-60VDC(1.75A)
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Output Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 4 (12-bit)
Analog input Type: 0~10V
Input Impedance: Voltage:10 MΩ
Input Accuracy: ±1%
Interface:WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation): 7
Outputs: 4*(Power Relay)
Continuous Current: 250VAC(7A)/30VDC(7A)
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Output Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 4 (12-bit)
Analog input Type: 0~10V
Input Impedance: Voltage:10 MΩ
Input Accuracy: ±1%
Interface:WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C

Operation Voltage: 10~30VDC/24VAC
Outputs: 8*(Power Relay)
Continuous Current: 250VAC(5A)/30VDC(5A)
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Output Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 4 (12-bit)
Analog input Type: 0~10V
Input Impedance: Voltage:10 MΩ
Input Accuracy: ±1%
Interface:WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C

Operation Voltage: 10~30VDC/24VAC
Inputs(Isolation):8
Outputs: 4*( (Source)
Continuous Current: 10-40VDC(1A)
Communication Baud Rate: 2400~921600bps
Isolation: YES(5000VDC)
Output Operating Frequency: 10HZ
Operation Temperature: -20 to +75 °C
Degree Of Protection: IP20
Analog inputs: 4 (12-bit)
Analog input Type: 0~10V
Input Impedance: Voltage:10 MΩ
Input Accuracy: ±1%
Interface:WIFI + RS-485 + USB
Channel Independent Configuration: YES
Sampling Rate: 10 sample/second (total)
CMR @ 50/60 Hz: 120 dB
Span Drift: ±50 ppm/°C
Zero Drift: ±18 μV/°C


Download





see more

Ordering Information




Remote Modules
1212: WIFI ADIO Remote Modules,4AI(0~20/4~20mA + PT-100/1000),2AO(0~20/4~20mA),2DI,2DO(Source Output),WIFI*1,RS-485*1,USB*1
1219: WIFI ADIO Remote Modules,8AI(0~20/4~20mA,J,K,T,E,R,S,B,Thermistor),4DI,WIFI*1,RS-485*1,USB*1
1251: WIFI DI Remote Modules,16DI,WIFI*1,RS-485*1,USB*1
1255: WIFI ADIO Remote Modules,8DI/4DO/4AI(0~10V),Motor Driver Output,WIFI*1,RS-485*1,USB*1
1255S: WIFI ADIO Remote Modules,8DI/4DO/4AI(0~10V),Source Output,WIFI*1,RS-485*1,USB*1
1260: WIFI ADIO Remote Modules,7DI/4DO/4AI(0~10V),Power Relay Output,WIFI*1,RS-485*1,USB*1
1269: WIFI ADIO Remote Modules,8DO/4AI(0~10V),Power Relay Output,WIFI*1,RS-485*1,USB*1
3290: WIFI DI Remote Modules,7DI,WIFI*1,USB*1
